Hloov ib qho ONU (Optical Network Unit) hauv tsev feem ntau yuav tsum ua kom muaj kev sib txuas ntawm fiber ntau thiab ua tiav cov cuab yeej sau npe / kev lees paub. Cov txheej txheem tsis nyuaj heev thiab tuaj yeem ua tiav los ntawm kev ua raws cov kauj ruam hauv qab no. Thov tuav tag nrho cov khoom fiber ntau maj mam thoob plaws:
1.Txhim kho ONU tshiab nrog koj ISP
ONUs raug kho los ntawm cov neeg ua haujlwm, yog li xyuas kom ONU tshiab txhawb nqa koj lub broadband hom PON (hom hom xws li EPON thiab GPON). Koj tuaj yeem tshawb xyuas daim ntawv lo rau hauv qab ntawm ONU qub lossis sab laj nrog koj qhov kev pabcuam ISP.
2. Sau Cov Lus Qhia Tseem Ceeb
Ua daim ntawv LOID code (tus lej tseem ceeb rau ONU sau npe / kev lees paub, qee zaum hu ua SN authentication code) los ntawm hauv qab ntawm ONU qub - yees duab rau siv.
Tsis tas li, sau koj qhov broadbandinternet account thiab password(siv rau PPPoE dial -up). Yog tias tsis nco qab, tiv tauj koj ISP kom rov pib dua lawv.
3.Power Off thiab Disassemble lub qub ONU
Tua lub hwj chim hloov ntawm lub qub ONU, ces unplug lub hwj chim cable, Ethernet cable (txuas mus rau koj lub router los yog computer), thiab fiber optic cable (lub nyias cable nrog ib tug xiav / ntsuab connector).
Yog tias tsim nyog, siv lub hau ntswj kom tshem tawm cov hlua khi ntawm ONU qub thiab txav cov cuab yeej qub rau sab.
4.Nruab qhov tshiab ONU thiab txuas kho vajtse
Ruaj ntseg ONU tshiab nyob rau hauv qhov chaw qub (lossis qhov chaw yooj yim), tsis txhob tshav ntuj ncaj qha thiab qhov chaw ntub dej.
Txuas lub fiber optic cable: Ntxig lub connector los ntawm phab ntsa fiber ntau qhov hluav taws xob rau hauv PON chaw nres nkoj ntawm ONU tshiab (feem ntau sau tias "PON" thiab yog qhov chaw nres nkoj ib leeg). Teem thiab ntxig maj mam kom txog thaum koj hnov ib "nias," qhia tias nws ruaj ntseg.Tsis txhob khoov lub fiber cable(lub vojvoog dabtsi yog khoov yuav tsum tsis pub tsawg dua 3 cm, los yog nws yuav tawg thiab ua rau poob ntawm kev sib txuas).
Txuas lub Ethernet cable: Txuas ib kawg rau hauv LAN chaw nres nkoj ntawm ONU tshiab (labeled "LAN1 / LAN2"; nyiam LAN1 yog muaj) thiab lwm qhov kawg rau hauv koj lub computer lossis router qhov chaw nres nkoj WAN.
Txuas lub hwj chim cable: Txuas tus tshiab ONU lub hwj chim adapter thiab qhib lub hwj chim hloov.
5.Register thiab Authenticate the New ONU
Qhib browser ntawm koj lub khoos phis tawj, nkag mus rau qhov chaw tswj hwm uas luam tawm hauv qab daim ntawv lo ntawm ONU tshiab (feem ntau 192.168.1.1), thiab nkag mus nrog lub npe neeg siv thiab tus password (tseem pom ntawm daim ntawv lo lossis muab los ntawm cov chaw tsim khoom).
Thaum nkag rau hauv, nrhiav qhov"Kev sau npe ntaus ntawv"los yog"LOID Authentication"kev xaiv. Nkag mus rau yav dhau los LOID code thiab nyem"Sau npe."
Tos li 5-10 feeb yam tsis muaj kev cuam tshuam fais fab. Saib xyuas lub teeb PON ntawm ONU tshiab: yog tias nws hloov los ntawm blinking mus rau ntsuab ntsuab, kev sau npe ua tiav. Yog tias nws tseem ntsais muag, LOID code yuav tsis raug lossis lub cuab yeej yuav tsis sib haum. Muab ob npaug rau- tshawb xyuas cov ntaub ntawv lossis tiv tauj koj ISP.
6.Configure Internet Parameters
Tom qab ua tiav kev sau npe, nrhiav"Internet Settings"hauv kev tswj interface, xaiv"PPPoE Dial-up,"nkag mus rau koj tus account broadband thiab password, thiab txuag cov chaw.
Yog tias koj xav siv Wi-Fi, mus rau"Wi-Fi Chaw,"teeb koj Wi-Fi lub npe thiab tus password, txuag, thiab rov pib ONU.
7. Kev sim thiab ua tiav
- Tom qab rov pib dua, saib LAN thiab Internet teeb ntawm ONU- lub teeb ntsuab qhia txog kev sib txuas hauv network.
- Xyuas kom pom tias lub teeb PON yog xim ntsuab thiab lub teeb LOS feem ntau tawm. Lub sijhawm no, koj tuaj yeem zoo siab qhib koj cov apps nyiam saib yeeb yaj kiab, ua si games, thiab txaus siab rau koj qhov kev paub hauv internet.
8. Ceev faj
- Fiber optic connector yog heev yooj yim. Ib txwm tuav lub vaj huam sib luag thaum ntsaws lossis tshem tawm -tsis txhob rub ntawm fiber ntau cable nws tus kheej.
- Yog tias ONU tshiab tsis sau npe, nws yuav yog vim ISP tau khi cov cuab yeej qub SN code. Hu rau cov neeg siv khoom pabcuam kom tshem tawm cov cuab yeej qub thiab qhib lub tshiab.
