Kev piav qhia
GQTM-8608B module tuaj yeem tsim lub teeb liab hauv DVB-T / C hom los ntawm HDMI cov tswv yim.
GQTM-8608B yog H264 encoding, DVB-T/C modulation integrated device los hloov HDMI teeb liab rau DVB-T/C RF tawm.
Lub GQTM-8608B module kho tus nqi compression rau qhov muaj bandwidth, siv cov modulation DVB-T/C tsis.
Specifications
| NPAJ | |
| Input Channel | 2 |
| Input Connectors | HDMI |
| Video System | 480i/p, 576i/p, 720p, 1080i/p |
| RF nkag | RF sib txuas |
| OUTPUT | |
| Ntau zaus | DVB -T: 177-858 MHz, DVB-C: 105 ~ 858MHz |
| Cov zis theem | 95 dBuV Min. |
| RF Level Kho | 0 ~ -30dB |
| Kauj ruam attenuation | 1dB ib kauj ruam |
| MER | 35dB Min. |
| MODULATION | |
| Video daws teeb meem | 1080p 25/30 Max |
| Video Compression | H.264 Baseline Profile Level4.0 |
| Video Bit Rate | 12 Mbps Max |
| Suab Compression | MPEG-2/AAC |
| Audio Bit Rate | 192 Kbit / s |
| Kho tau teb | Lub Npe Kev Pabcuam, Lub Npe Lub Npe, Kev Pabcuam ID, LCN, NIT Version, TS ID, Network Name, Network ID, Thawj Net ID, Lub Tebchaws |
| DVB-T | |
| Txuj | DVB-T (ETSI EN 300 744) |
| Carrier (OFDM hom) | 8K |
| Guard Intervals | 1/32 |
| Tus nqi Code (FEC) | 7/8 |
| Cov hnub qub | 64 QAM |
| Bandwidth | 6MHz, 7MHz, 8MHz, 7-8MHz |
| DVB-C | |
| Txuj | DVB-C (ETSI EN 300 429 V1.2.1) |
| Lub hnub qub | 16, 32, 64, 128, 256 QAM |
| Cim tus nqi | 2.0 ~ 6.96 Cov cim |
| Bandwidth | 7 MHz, 8 MHz |
| MANAGEMENT / CONTROL | |
| Kev teeb tsa | 6 Local keys ntawm Upper cover |
| Web Management | RJ-45 Ethernet chaw nres nkoj |
| GENERAL | |
| Zaub | LCD vaj huam sib luag @ 2 x 16 cim (nyob rau pem hauv ntej vaj huam sib luag) |
| Fais fab mov | 12V ADAPTER |
| Kev noj haus | <10 W |
| Lus | Lus Askiv |
| Qhov ntev | 235 x 160 x 40 mm |
| Qhov hnyav | 800g |
