Piav
- Tsis muaj epoxy, fiber ntau polishing, cov cuab yeej tshwj xeeb, lossis fusion splicer xav tau.
- Ceev thiab yooj yim fiber ntau termiQuick thiab yooj yim fiber ntau txiav nyob rau hauv tsawg tshaj li ob feebnation nyob rau hauv tsawg tshaj li ob feeb.
- Precision mechanical alignment kom ntseeg tau tias tsis muaj qhov nkag.
- Superior optical kev ua tau zoo.
Parameters & Specifications
| Hom Connector | SC, Simplex |
| Kab Kab | 0.9 / 2.0 / 3.0 hli |
| Fiber hom | Singlemode |
| Polish | UPC / APC |
| Insertion Loss | UPC: Tsawg dua lossis sib npaug rau 0.35dB, APC: Tsawg dua lossis sib npaug rau 0.35dB |
| Rov Los Los | UPC: Ntau dua lossis sib npaug rau 45dB, APC: Ntau dua lossis sib npaug rau 50dB |
| Kev Ntsuas Siab | Ntau dua lossis sib npaug li 50N |
| Ua haujlwm kub | -40℃~ +75 degree |
| Quantity ib pob | 10 |
| Ua raws | Tsim los rau Telcordia GR-20-CORE, GR326 thiab TIA / EIA 568C, RoHS |
