Khoom piav qhia

Ntsiab nta

● Kev them nyiaj yug ntaus ntawv - raws li tus nqi txwv thiab tswj bandwidth

● Ua raws li IEEE802.3ah Standard & ITU-T G.984 tus qauv

● Txog 20KM kis tau tus mob nrug

● Txhawb cov ntaub ntawv encryption, pab pawg tshaj tawm, chaw nres nkoj Vlan sib cais, thiab lwm yam.

● Txhawb Dynamic Bandwidth Allocation (DBA)

● Txhawb ONU pib - tshawb pom/Txuas kev tshawb nrhiav/cov chaw taws teeb hloov kho software;

● Txhawb chaw nres nkoj VLAN teeb tsa

● Txhawb lub zog - tawm lub tswb muaj nuj nqi, yooj yim rau kev txuas teeb meem nrhiav pom

● Txhawb kev tshaj tawm xov xwm stormresistance muaj nuj nqi

● Txhawb qhov chaw nres nkoj khi

● Txhawb chaw nres nkoj xa mus

● Txhawb ACL kom teeb tsa cov ntaub ntawv pob ntawv lim tau yooj yim

● Kev tsim tshwj xeeb rau kev tiv thaiv kev puas tsuaj kom ruaj khov

● Txhawb software hloov kho hauv online

● Txhawb TR069 rau ACS (Auto Config Server)

● Txhawb PPPoE/DHCP Server/IPTV/VolP/NAT

Lub Suab Service Functions

● Nrog lub plawv dhia ua haujlwm, txhawb nqa lub ntsiab tsim khoom muag muag;

● Txhawb siab / qis ceev hom pob tshab kis tau tus mob, T38 ob fax;

● Txhawb siab -Modem ceev (56Kbps) hu xov tooj; txhawb RFC2833 thiab rov ua dua RFC2833, ringing, MD5 ntawv pov thawj, hu rau xa mus, hu tos, tus xov tooj kub, tswb, luv luv hu thiab lwm yam nqi - ntxiv cov kev pabcuam;

● Kev them nyiaj yug SlP(tshaj nrog lMS), H.248, MGCP peb VolP raws tu qauv, thiab lub mos hloov platform lub ntsiab yuav ua tau zoo intercommunication;

● Txhawb 1 PoTS interface thiab peb tog hu, peb tog txhawb kev sib xyaw hauv zos;

● Txhawb POTS chaw nres nkoj GR909 kab xeem ua haujlwm;

● Txhawb dynamic PPPoE, DHCP thiab zoo li qub lP;

● Txhawb ITU-TG.711,G.723.1,GTo tshem tawm qhov ntev tshaj plaws 128ms;

● 7 * 24 teev hu tsis tau tsawg dua lossis sib npaug li 0.01%;

Specification

Technical Parameter

Tus neeg siv interface	1 * 10/100/1000MRJ45 3 * 10/10OM RJ45 1 * POV 1 * USB
PON	EPON & GPON hom hloov kho Hom lnterface: SC-UPC/SC-APC Network coverage vojvoog: 20KM GPON: nce 1.25Gbps / downstream 2.5Gbps Transmission optical zog: 0.5dBm ~ 5dBm Optical txais rhiab heev: -7dBm ~ -28dBm EPON: nce 1.25Gbps / downstream 1.25Gbps Transmission optical zog: 0dBm ~ 0.4dBm Optical txais rhiab heev: -7dBm ~ -27dBm
Ethernet	1 * 10/100/1000M+3*10/100M auto-kev sib tham Full/half duplex hom RJ45 connector Auto MDI/MDI-X 100 m nrug
Loj	140mm (L) x 90 hli (W) × 30mm (H)
Ib puag ncig	Ua haujlwm kub: 0 ° -60 ° C Kev khiav dej num: 10% ~ 85% tsis yog -condensing Cia kub: -40 ℃ ~ 80 ℃ Cia cov av noo: 5% ~ 95% tsis yog -condensing
Fais fab mov	DC 12V / 1A Lub zog interface loj: 2.1mm / 5.5mm
Kev siv fais fab	<7.5W
Pots chaw nres nkoj	1 * RJ11 nrog 3REN Max 1 km nrug Lub nplhaib sib npaug, 55V RMS
Txiv neej	WEB/TELNET/TR069/OMCI/OAM
