GPU 6352 feem ntau yog siv rau hauv cov xwm txheej uas yuav tsum tau muaj bandwidth siab thiab kev ua haujlwm siab. Nws txuas nrog 10Gbps thiab 1Gbps Ethernet interfaces thiab txhawb nqa XG(S)-PON thev naus laus zis, muab cov ntaub ntawv sib kis tau zoo thiab kev ntseeg siab, ua rau nws haum rau ntau yam kev xav tau kev sib txuas lus niaj hnub no.
GPU 6352 yog tsim los rau cov xwm txheej nrog lub network bandwidth siab thiab cov ntaub ntawv xa tawm tus nqi, tshwj xeeb tshaj yog nyob rau hauv ib puag ncig uas xav tau bandwidth siab xws li tsev, chaw lag luam, thiab cov chaw khaws ntaub ntawv. Nws ntau qhov sib cuam tshuam ntawm 10Gbps thiab 1Gbps tuaj yeem ua tau raws li cov kev xav tau ntawm cov chaw sib txawv, txhawb cov ntawv thov xws li siab -txhais video, huab xam, thiab cov ntaub ntawv loj, nrog rau kev lag luam dav dav.
Specifications
|
○Hardware Parameter |
|
|
Dimension |
140mm * 140mm * 36.5mm (L * W * H) |
|
Net nyhav |
316g |
|
Kev ua haujlwm |
Ua haujlwm kub: -10 ~ +55 degree Ua haujlwm av noo: 5 ~ 95% (tsis yog-condensed) |
|
Kev khaws cia |
Cia kub: -40 ~ +70 degree Cia cov av noo: 5 ~ 95% (tsis yog -condensed) |
|
Fais fab adapter |
12V/1A |
|
Fais fab mov |
12W |
|
Interface |
1 * 10GE+1*GE |
|
Qhov taw qhia |
SYS, PON, LOS, LAN1, LAN2 |
|
○Interface parameter |
|
|
PON interface |
l SC ib hom, SC / UPC connector l TX optical zog: 6dBm (XGS-PON), 5dBm (XG-PON) l RX rhiab heev: -28dBm l Overload optical zog: -8dBm l Transmission nrug: 20km l Wavelength: l XG(S)-PON: DS 1577nm/US 1270nm |
|
10G PON txheej |
l ITU-T G.987(XG-PON) l ITU-T G.9807.1 (XGS-PON) |
|
Tus neeg siv interface |
l 1 * 10GE, Auto-kev sib tham, RJ45 chaw nres nkoj l 1*GE, Auto-kev sib tham, RJ45 chaw nres nkoj |
|
○Cov ntaub ntawv muaj nuj nqi |
|
|
Kev sib txuas hauv Is Taws Nem |
Txhawb Choj hom |
|
Tswb |
l Txhawb Tuag Gasp l Txhawb Port Loop Detect |
|
LAN |
l Txhawb Port tus nqi txwv l Txhawb Kev Tshawb Nrhiav Loop l Txhawb Flow tswj l Txhawb cua daj cua dub tswj |
|
VLAN
|
l Txhawb VLAN tag hom l Txhawb VLAN pob tshab hom l Txhawb VLAN lub cev hom l Txhawb VLAN hybrid hom |
|
Multicast |
l IGMPv1/v2/Snooping l Txhawb multicast raws tu qauv VLAN thiab multicast cov ntaub ntawv stripping l Txhawb kev txhais lus multicast |
|
QoS |
Txhawb WRR, SP + WRR |
|
O&M |
l WEB/TELNET/SSH/OMCI l Txhawb nqa tus kheej OMCI raws tu qauv thiab kev tswj hwm kev sib koom ua ke ntawm VSOL OLT |
|
Firewall |
Txhawb IP chaw nyob thiab chaw nres nkoj filtering muaj nuj nqi |
|
Lwm yam |
l Txhawb nqa log muaj nuj nqi |
